| Hardware & Accessories |
Chassis:
Pressure formed non-ferrous alloy
Chassis and end covers:
Cold drawn brass, bronze or stainless steel
Door Thickness:
1-3/4' (44.45 mm) standard, available for thick doors
Handing: Handed. Specify LHRB or RHRB
Dogging: Allen type only.
Top/Bottom Bolts: N/A
Latchbolt:
Brass, 3/4' (19.05 mm) throw
Crossbar arms:
Forged brass and stainless steel
Crossbar:
1' (25.40 mm) brass, bronze and stainless steel tubing, .062' (1.5875 mm) thick
Crossbar projection:
4-1/2' (114.3 mm) neutral, 2-3/4' (69.85 mm) depressed
Opening Height: N/A
Fire Exit Hardware-up to:
-4` x 7`2' single door
-8` x 7`2' pairs of doors (with FS1700)
Finishes:
US3,US4,US10,US10B,US26,US26D.
|
|
|
 |
|
|
|
